ZTPA-30CL-D1W
ZTPA-30CL-D1W
Features
- Outdoor design, waterproof unit, suit for outdoor and indoor.
- Small and elegant appearance, suit for all kind of decoration place.
- With power tap, independently adjustable, multiple choices of input mode.
- Solid aluminum alloy box, not easy to deformation and rust.
- E type pure copper wire audio transformer to ensure fidelity of audio output.
- Equipped with multifunctional mounting bracket, convenient installation
- Equipped with multifunctional mounting bracket, convenient installation
- With 3 "Gray polypropylene drum paper full frequency cone-type bass unit and 2"
- treble unit combination, frequency response wide, bass level clear, treble clear and bright.
| Model Specifications | ZTPA-30CL-D1W | |
|---|---|---|
| Speaker Unit | 3″×2, 2″×1 | |
| Rated Power（RMS） | 30W | |
| Power Adjutment | 70V | 1W-2W-4W-8W-15W |
| 100V | 2W-4W-8W-15W-30W | |
| 8Ω/4Ω | 30W | |
| Freq.Response | 140Hz-20kHz | |
| Sensitivity （1m,1W） | 87±3dB | |
| Max SPL（1m） | 102±3dB | |
| Dimension（L×W×H） | 376×109×102mm | |
| Net weight | 3kg | |
