| SPECIFICATION |
| ➤ Connectivity : WiFi (AP/STA) Bluetooth |
| ➤ Resolution :1080P 720P*4 |
| ➤ Algorithms :ADAS DMS |
| ➤ Power:DC 9-30V Low Power, always on |
| ➤ Expansion Cable :Standard (included) |
| ➤ Antenna :Built-in |
| interface |
| ➤LED indication : Red (Power), Blue (Cellular), Green (GNSS) |
| ➤External memory : TF card (up to 256GB 2) |
| ➤USB : Type-C |
| ➤WiFi : 2.4GHz. Support AP Mode/STA Mode/WiFi Direct |
| ➤Bluetooth : BLE 4.0 |
| ➤Microphone : Support |
| ➤Speaker : Support |
| ➤Digital I/Os : 2: SOS 2, 1 Relay 2 Reserved inputs |
| ➤Analog I/Os : 1*CVBS-OUT |
| ➤Serial ports : 1*RS232, 1*TTL |
| ➤Sensor : 3-Axis accelerometer |
| Feature |
| ➤ADAS : FCW HMW LDW |
| ➤DMS (optional) : Phone use, Smoking Distraction, Yawning Eyes closed, No face detected |
| ➤Configuration support : GPRS, SMS, Memory card, APP |
| ➤Firmware update : USB cable. Memory card, OTA |
| Physical specification |
| ➤Dimensions : 118.0 x 97.0 x 32.0mm |
| ➤Weight : 350g |
