ZTSPA-A3606-M
ZTSPA-A3606-M
Features
- High contrast 128X64 English dot matrix screen, built-in audio source information
- at a glance, automatic screensaver function
- MP3 can realize 4 different styles of music playback, which is convenient and fast
- to be in place with one click
- MP3 can realize multiple playback modes, random/single loop/full song loop
- 2 RCA Lotus line inputs
- 100V, 70V constant voltage output & 4Ω-16Ω constant resistance output
- Saturation distortion and LED warning
- Built-in intelligent temperature detection drives air cooling, using low-noise fan
- Built-in infrared frequency receiver and one-key remote control function
- High and low sound adjustment
| Model | ZTSPA-A3606-M |
|---|---|
| Power supply: | AC220V/50Hz |
| Microphone SNR : | >68dB, Line: >82dB |
| Frequency response: | 60Hz-18KHz (±2dB) |
| T.H.D < 0.1% at 1KHz | |
| Tone: Bass: | ±10dB at 100Hz, Treble: ±10dB at 10KHz |
| Receiving frequency range: | 76MHz-108MHz |
| Microphone input sensitivity & impedance: | 8mV/600Ω unbalanced |
| Line input sensitivity & impedance: | 250mV/10KΩ unbalanced |
| Line output sensitivity & impedance: | 1V/600Ω unbalanced |
| Mute adjustment: | 0-38dB |
| Output power: | 360W |
| Power consumption: | 10-450W |
| Dimensions: | 482 x 352 x 90mm |
| Weight: | 14.5KG |
