ZTPA-350W6Z
ZTPA-350W6Z
Mixer Amplifier with USB & Tuner
Features
- 100V & 4-16 Ω, rated power 350W
- Support USB / SD / FM radio, with built-in chime
- 4 MIC inputs, Mic 1 with priority and muting fun
- 3 AUX line input & 1 AUX line output for power extension
- Each AUX & Mic input with individual volume
| Model | ZTPA-350W6Z |
|---|---|
| Rated Output | 350W |
| Output Regulation | Less than 3dB, from off-load to full load |
| Input sensitivity | MIC: 3.0mV(±0.5mV) |
| LINE: 300mV(±50mV) | |
| Frequency Response | 80Hz-16kHz (±3dB) |
| Distortion | Less than 1% (at 1kHz, 1/3 rated output voltage) |
| Ratio of Signal to Noise | MIC: more than 71dB |
| LINE: more than 85dB | |
| Tone | Bass: ±10dB（at 100Hz） |
| Treble: ±10dB（at 10kHz） | |
| Protection | DC voltage; overload; short-circuit. |
| Mute | Input signals from MIC 1 override other input signals |
| Power Requirements | AC 220-240V/50-60Hz |
| Power Consumption | 650W |
| Outer Packing Size(mm) | (L×W×H)520×430×195 |
| Unit Size (mm) | (L×W×H)418×355×88 |
| Gross Weight | 17kg |
| Net Weight | 15kg |
