ZTNX-EG32CH4K-H2FR-A2

ZTNX-EG32CH4K-H2FR-A2

Features

  • Support 32CH 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/ 720P/960H/D1/CIF IPC Input
  • H.265S/H.265+/H.265/H.264
  • Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
  • Multi-type recording: manual / timed / motion / sensor / POS / AI recording
  • Playback : 16CH simultaneous playback
  • Search : time slice, time, event, tag and smart search
  • Support face detection and comparison
  • Support POS information overlay on live view and playback
  • DHCP, DDNS, PPPoE network protocol
  • Compatible with third-party IPCs, such as ONVIF, etc.
  • Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
  • Authorization management, log view and device status view
  • Support NAT function and QRCode scanning by mobile phone and PAD
  • Powerful smart phone & Pad surveillance with iOS and Andriod OS
  • 4K output, true high resolution display

ModelZTNX-EG32CH4K-H2FR-A2
Comparison
Capability

18 pictures / second
Working Environment-10~ 50°C, 10% ~90% humidity
Consumption≤ 20W ( without HDD )
Decoding CapabilityLive View/Playback1CH 12MP/4CH 1080P
Face Detection Performance (AI by Device)2 CH (2MP)
Output4 CH
Face Match
Performance
6 CH
Input8 CH local alarm input
Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/
720P/960H/D1/CIF
Resolution12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/
720P/960H/D1/CIF
AI Mode24CH (HDMI1)
FaceFace Detection Performance (AI by IPC)32 CH
Audio
Network Input32 CH IPC audio input
VideoIP Video Input32 CH IPC input
Face Picture
Database
32 libraries
10000 Face Pictures
Dual Output Mode32CH (HDMI1) +4CH (HDMI2)
Network
Bandwidth
192Mbps/192Mbps
(incoming/outgoing)
Dimensions(mm)380 × 268 × 45 ( W × D × H )
Face Picture
Adding
Add face pictures through APP, WEB and external import
Database
Management
Add, modify, delete and search face pictures
FaceStatistical Graph of InformationBar graph
CertificateCE, FCC
Environmental
Protection
Complies with Directive EU RoHS, REACH and WEEE
OthersPower SupplyDC 12V 4A
Multi-Screen Display ModeModeDual output mode (default mode): supports HDMI2 output, but doesn’t support AI by device
AI mode: HDMI2 output and 12MP video input (live view/playback)
are unavailable, but 8MP video input supports
RecordRecord StreamDual stream recording
SystemOSEmbedded Linux
CompressionG.711(U/A)
OutputHDMI1 : 3840 × 2160/1920 × 1080 / 1280 × 1024 / 1024 × 768
HDMI2 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA ×1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA and HDMI1 output the same video source
Smart SearchHighlighted color to display the camera record in a certain period of time, different colors refers to different record
Mobile DeviceOSIOS, Android
AlarmModeManual, sensor, motion, exception, smart events, etc.
PlaybackSimultaneous PlaybackMax 16CH
Client ConnectionMax. 20 users access
Frame RateNTSC: 30fps; PAL: 25fps
Remote ControllerOptional
FunctionPlay, pause, FF, FB, digital zoom, etc.
2-way AudioRCA × 1
Local OutputRCA × 1
TriggeringRecord, snap, preset, e-mail, etc.
NetworkInterfaceRJ 45 1000 Mbps × 2
StorageHDD InterfaceSATA × 2, max 12T for each HDD
Face Picture
Search
Search by picture is supported
Statistical Mode of InformationStatistics by day, week, month, quarter as well as customized time period
Face Picture
Comparison
Support allow list, block list and stranger match alarm
Other
Functions
FisheyeSupports fisheye dewarping via Web Client and mobile APP
ProtocolTCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x, RTSP, SNMP, ONVIF, etc.
SearchTime slice / time / event / tag / smart search
TrackTrack display on a map
BackupLocal BackupU disk, USB mobile HDD
USBUSB 3.0 × 1 ; USB 2.0 × 2
Video Structure AnalysisHuman/Vehicle
Classification
Yes
Plate RecognitionYes
Network BackupYes
External
Interface
RS 485Yes (full-duplex), connect to PTZ or keyboard
