ZTNX-64CH-FRPRO
ZTNX-64CH-FRPRO
ZTNX-64CH-FRPRO supports 64CH 12MP /8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280 × 1024 / 960P /720P high definition IP video input, which adopts the most advanced SOC technique to ensure high definition recording in each channel and realize outstanding robustness of the system.
ZTNX64CH-FRPRO supports 64 CH IP input, simultaneous 16 CH playback, and 4K high definition display.
The series of products can meet different security requirements of home, financial, commerce, enterprise, transportation and government, etc.
Features
- Supports /64CH 12MP /8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280 × 1024 / 960P / 720P IP input
- Standard H.265 high profile compression format to get high-quality video at much lower bit rate Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
- Multi-mode recording: manual / timer / motion / sensor/smart events
- Playback: 16 CH simultaneous playback
- Search: time slice, time, event, tag, smart and target database search
- Support face detection and comparison
- Support multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video tampering, etc.
- Support POS information overlay on live view and playback
- Support RAID0, 1, 5, 6, 10
- Express and flexible backup via USB, network and so on Pentaplex : preview, record, playback, backup and remote access DHCP, DDNS, PPPoE network protocol
- Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
- Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device Multi-user online simultaneously
- Authorization management, log view and device status view
- 4K output, true high resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QRCode scanning by mobile phones
- Powerful mobile surveillance by smart phones with iOS and Andriod OS
| Model | ZTNX-64CH-FRPRO | |
|---|---|---|
| System | OS | |
| Video | IP Video Input | 64 CH IPC input |
| Incoming Bandwidth (Mbps) | 640 | |
| Outgoing Bandwidth (Mbps) | Display Priority: 128 Network Priority: 640 |
|
| IP Video Input Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/ 720P/960H/D1/CIF |
|
| Output | HDMI1: 3840 × 2160@60fps / 3840 × 2160@30fps/ 1920 × 1080 / 1280 × 1024 / 1024 × 768 HDMI2: 1920 × 1080 / 1280 × 1024 / 1024 × 768 HDMI3: 1920 × 1080 / 1280 × 1024 / 1024 × 768 HDMI4: 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 |
|
| Compression | Standard H.264/H.265 | |
| Audio | Network Input | 64 CH |
| 2-way Audio | RCA × 1 | |
| Local Output | RCA × 1 | |
| HDMI Audio | Yes | |
| Compression | G.711(U/A) | |
| Record | Record Stream | Dual stream recording |
| Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/ 720P/960H/D1/CIF |
|
| Frame Rate | 25fps (PAL) / 30fps(NTSC) | |
| Mode | Manual, timer, motion, sensor, smart events | |
| Playback | Simultaneous Playback | Max 16 CH |
| Search | Time slice / time / event / tag search | |
| Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refers to different record events | |
| Decoding Capability | Live/Playback | 1CH 12MP/ 4CH 5MP/9CH 720P/16CH 720P |
| Alarm | Mode | Manual, sensor, motion, exception, smart events |
| Input | 16 CH local alarm input; IPC alarm input supported | |
| Output | 4 CH | |
| Face | Face Detection Performance (AI by IPC) | 64 CH |
| Face Detection Performance (AI by device) | 4CH | |
| Face Match Performance | 16 CH | |
| Comparison Capability | 36 pictures / second | |
| Face Picture Database | 32 libraries 10000 Face Pictures |
|
| Face Picture Search | Search by picture is supported | |
| Database Management | Add, modify, delete and search face pictures | |
| Face Picture Adding | Add face pictures through APP, WEB and external import | |
| External face picture enrollment | Resolution: 128 x 128 – 1920 x 1080 Size: less than 70KB Format: jpg, jpeg |
|
| Face Picture Comparison | Support common, allow list and block list alarm | |
| Face Track | Yes | |
| Map of Face Track | Resolution: ≤ 2560 x 1920 Size: ≤ 512KB Format: jpg, jpeg |
|
| Statistic Graph of Face Information | Bar graph | |
| Statistic Mode of Face Information | Statistics by day, week, month, quarter as well as customized time period |
|
| Network | Interface | RJ45 10 / 100 / 1000 Mbps × 2 |
| Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x |
|
| Mobile Device | OS | iOS, Andriod |
| Storage | HDD Interface | SATA × 8, max 10T per HDD; e-SATA × 1 |
| RAID Type | RAID 0, 1, 5, 6, 10 | |
| Backup | Local Backup | U disk, USB mobile HDD |
| Network Backup | Yes | |
| Port | USB | USB 2.0 × 2, USB 3.0 × 1 |
| Remote Controller | Optional | |
| RS 485 | Yes (full-duplex), connect to PTZ or keyboard | |
| Others | Power Supply | ATX 200W |
| Consumption | ≤ 50W ( without HDD ) | |
| Dimensions | 445mm×436mm×90mm | |
| Working Environment | -15 ～ 50 ℃， Humidity: 10% ～ 90% |
|
