ZTJ-IPCT-PRO
ZTJ-IPCT-PRO
- 10.1 inch capacitive touch screen
- Android 6.0 operating system
- Maximum 4 screen display mode
- Supports the network access to the full range of our PTZ cameras
- Supports PTZ control, preset, cruise and track setupand calling
- ONVIF protocol supported
- Up to 1024 devices to be added
- Supports USB flash disk upgrade, USB mouse
- Supports viewing images on the touch screen or outputting images on the external
- monitor via HDMI interface
| Model Specifications | ZTJ-IPCT-PRO |
|---|---|
| Screen size | IPS 10.1 inch screen， 1280*800 capacitive touch screen |
| Display s | HDMI 4K@30fps |
| Decoding capability | Max.H.264 1CH 1080p@60fps/ 4CH 720p@30fps Max.H.265 1CH 4k@30fps |
| Protocol | ONVIF 2.4 |
| Function | Up to 1024 devices to be added PTZ Control; Calling or setting preset, cruise, scan, etc |
| System settings | Supports language settings, password modification and USB flash disk upgrade |
| Power | Standard 5.5/2.1 Power interface， DC 12V2A±10% |
| Interfaces | 1 RJ45 Ethernet port 1 RS485 1 RS232 1 HDMI output(V 1.3) 1 USB2.0 port 1 standard 3.5mm headphone jack |
| Operation interface | 4D Joystick, Buttons |
| Power consumption | ＜15W |
| Standby current | ＜100mA |
| Mean time between failures | ＞30000 |
| Working humidity | 10%-90%(RH) |
| Working temperature | -10°C-40°C |
| Storage temperature | -40°C-60°C |
| Dimensions(mm) | 445x179x118 |
| Net weight（kg） | Approx. 1.388 |
