| Camera |
| image sensor | 2.0MP 1/2.9 cmos |
| LUX | COLOR 0.05Lux@F1.2; B/W 0.005Lux@F1.2; |
| S/N | ≥50db(AGC OFF) |
| WDR | DWDR；＞80db |
| Lens |
| Focal Length | 2.8mm |
| Lens Type | Fixed-focal |
| Angle of View (H) | 102.5° |
| Angle of View (V) | 55.2° |
| Angle of View (D) | 122.1° |
| Video |
| Coding Format | H.264 |
| reslution | main stream :1920*1680，1-20FPS/S 1280*720，1-30 FPS/S |
| sub stream : 640*360 ,1-30FPS/S |
| Video Coding Compression | 128Kbps-8192bps continuous adjustable |
| Subtitle Overlay | Support channel name、Date、Code stream information overlay,Overlay place adjustable |
| Data Transmission & Storage |
| Data Record | Video, picture |
| Protocol | All Net Connect / ONVIF 2.6 |
| Mobile | Support IOS ,Android |
| Browser | Support IE6.0 and above browser Client Browser |
| IR Board |
| The product name | infra red light led |
| lamp cup piecs | 18 piecs |
| Voltage | 12V DC |
| warm light distance | up to 30M |
| General |
| Power | DC12V /POE |
| housing | plastic / white |
| Operation Temperature | -10℃ ~ +50℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Dimension | 90.5(W) x 80(H) x 80(D)mm |
| Weight | 300g |
| Weight | 156.2g |
