| System | Operating System | Linux | |
| Display | Display Screen | 7 inch IPS touch screen | |
| Display Resolution | 1024 ×600, brightness:300 cd/m2 | |
| Operation Method | Capacitive touch screen | |
| Video | Video Input | Max. 4CH videos can be viewed simultaneously | |
| Network Input Resolution | 6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF | |
| Compression | H.265+/H.265/ H.264 | |
| Audio | Local Input | Built-in microphone | |
| Local Output | Built-in speaker | |
| Compression | G.711(U/A) | |
| Record | Resolution | Up to 8MP | |
| Frame Rate | NTSC: 30fps; PAL:25fps | |
| Playback | Simultaneous Playback | Max.1CH | |
| Performance | Linked IPC | Max. 16 CH | |
| Linked Indoor Extensions | Max. 5 | |
| Network | Interface | RJ 45 100 Mbps self-adaptive Ethernet port ×1 | |
| Wireless Network | WiFi 802.11b/g/n | |
| Protocol | TCP / IP, DHCP, DNS, NTP, etc. | |
| Incoming/Outgoing Bandwidth | 40/40Mbps | |
| Interface | Audio | Built-in speaker and microphone, support noise suppression and echo cancellation | |
| Storage | Built-in micro SD card slot, up to 256GB | |
| Reset | Yes | |
| Alarm Input | 8CH | |
| Wi-Fi | Yes,2.4G Wi-Fi | |
| Unlocking Button | Yes | |
| RS 485 | Reserved | |
| Power Output | DC12V 200mA (only available when DC12V power supply is used) | |
| Others | Power | DC12V/POE | |
| Power Consumption | < 6W | |
| Dimensions(mm) | 180.6 135.6 26.8 | |
| Weight (net) | Approx.0.36kg | |
| Installation | Wall mounting | |
| Working Environment | -20 ~50 , Humidity: less than 95% (non-condensing) | |
| Certificate | CE, FCC | |
| Environmental Protection | Complies with Directive EU RoHS, REACH and WEEE | |
