ZTEGS-4P2U
ZTEGS-4P2U
- Total 65W Power Supply
- 4 ports PoE
- 2 ports Uplink
- AI Watchdog Function
- 6KV Lightning & 8KV ESD Protection
- Support bt 60W High Power
- Auto-Adaption 250m Transmission
| Model Specifications | ZTEGS-4P2U |
|---|---|
| Ports | PoE (1~3):10/100Mbps PoE ports (RJ45) PoE (4):10/100Mbps PoE port (RJ45),Support bt 60W High Power LAN (1~2):10/100Mbps uplink ports (RJ45) |
| Transmission Rate | 200Mbps Full Duplex; 10 or 100Mbps Half Duplex |
| Transmission Distance | 100Mbps /10Mbps,Auto-Adaption 250m |
| Performance Specification | Bandwidth:1.2Gbps |
| 3.6mm | |
| Network Latency (10 to 100Mbps): ⛄16μs (use the 64byte package size) |
|
| MAC address table: 2K | |
| The Frame Filter & Transmission Rate: 14800pps the most for 10M port, 148800pps the most for 100M port |
|
| Networking Standard | IEEE 802.3i 10BASE-T |
| IEEE 802.3u 100BASE-TX | |
| IEEE 802.3x Flow Control | |
| IEEE 802.3af/at/bt Power over Ethernet | |
| Power Support | Power Input: AC 90~240V Total≤65W AI Watchdog: Port 1~4 Power Output: PoE1~3 Port:1/2(+52V),3/6(GND)≤30W PoE 4 Port:1245(+53V),3678(GND) Compatible1/2(+52V),3/6(GND)≤60W |
| Protection Level | Lightning Protection:6KV, Per: IEC61000-4-5 ESD Protection:8KV, Per: IEC61000-4-2 |
| Physical Specifications | Size(L*W*H): 187mm*139mm*43mm, Weight: 1.0KG |
| Working Environment | Operating Temperature: -30¥~60¥ |
| Storage Temperature: -40¥~70¥ | |
| Operating Humidity: 10%~90% Non-condensing | |
| Storage Humidity: 5%~90% Non-condensing | |
| Certification | CE Mark |
| FCC Part15 Class B | |
| Functions | RoHS 2.0 |
| Warranty | Whole Device: 1 year |
| Package Content | AC Power Cable,User Manual |
