IVEX - PL-3011RA
IVEX - PL-3011RA
- Ex Certifications : IECEx / ATEX / KCs / NEPSI / JPEx
- Ex Certifications (Gas) : Ex d IIC T6 Gb, Zone 1 & 2
- Ex Certifications (Dust) : Ex tb IIIC T85°C Db, Zone 21 & 22
- Electropolished AISI 316L Stainless Steel / Lost-wax casting mold structure without welds
- Cable Entry : 1 x 1/2" NPT
- Operating Temperature : -25°C ~ +65°C
- Ingress Protection Rating : IP66
- 2.7 ~ 12 mm Motorized Lens
- Full HD 2 Megapixel, 1∕2.8” High Sensitivity STARVIS CMOS Sensor
- ONVIF support
- Minimum Illumination : 0.03 Lux
- PoE Class 3 (IEEE 802.3af) support
- Video Quality Adjustment : H.264 / H.265 / MJPEG
- Camera / Housing / Exclusive multi-bracket / Explosion Proof Cable Gland / Explosion Proof Cable (Option) / All-in-one, Maximized Installation and Convenience
| MECHANICAL PART | |
|---|---|
| Model | IVEX – PL-3011RA |
| Construction | AISI 316L Stainless Steel |
| Window | Tempered Glass |
| Ex Certifications | IECEx/ATEX/JPEx/NEPSI/KCs/KC |
| Ex Certifications (Gas) | Ex d IIC T6 Gb, Zone 1 & 2 |
| Ex Certifications (Dust) | Ex tb IIIC T85°C Db, Zone 21 & 22 |
| Ingress Protection Rating | IP66 |
| Operating Temperature / Humidity | -25°C ῀ +65°C / Less than 90%RH |
| Dimensions | 107.2(W) × 148(H) × 187(L) mm |
| Weight | About 3 kg |
| Supply Voltage | PoE Class 3 (IEEE 802.3af) |
| Cable Entry | 1 × ½” NPT |
| CAMERA PART | |
|---|---|
| Sensor Type | 1/2.8″ Sony STARVIS CMOS Sensor |
| Effective Pixels | 1945(H) x 1097(V) / 2.13 Megapixels |
| Scanning System | Progressive Scan |
| Lens | 2.7 ~ 12 mm Motorized Lens / F1.4 |
| Angular Field of View (D/H/V) | D:138.0°(W)~40.0°(T) / H:103.0°(W)~30.8°(T) / V:74.4°(W)~23.3°(T) |
| Minimum Illumination | 0.03 Lux |
| Day & Night | True Day & Night (Auto, Color, BW) |
| Electronic Shutter Control | Auto / Manual (1/30 ~ 1/30,000 sec) |
| WDR | True WDR (On / Off) |
| DNR | 3 DNR |
| Privacy Zone | Off / On (4 Programmable Zone) |
| Video Quality Adjustment | H.264 / H.265 / MJPEG |
| Resolution | 1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 640×480, 320×240 |
| Frame Rate | 1920x1080p @30fps |
| Bitrate Control | CBR/VBR, Network Bandwidth Control |
| Streaming Capability | Dual Stream : Main-stream (1080p), Sub-stream (D1) |
| Number of Concurrent Users | Up to 4 Users |
| Ethernet | Ethernet 10/100 Base-T |
| IP | IPv4 / IPv6 |
| Protocol | TCP/IP, HTTP, STP/RTSP, UDP, DHCP, FTP, SMTP, NTP, ARP, ICMP, DDNS, ONVIF |
| ONVIF | Yes (Profile-S) |
